Individualized Ventilation

A question I always ask myself, why are we treating our patients like cars?

Need to fill gas/oil tanks/tires with certain volumes and up to certain pressures.

Is the human lung the same as a car part? If you agree that our lungs are different, then please ask yourself why are we giving certain volume (6 ml/kg) every breath, and to a certain pressure (plateau < 30 cmH2O), and applying some tables (PEEP-FiO2) to our patients.

Just to be clear and before you trash this blog, I’m not advocating giving high tidal volumes, pressures to a sick lung. We are talking about

“Individualized Ventilation”

Let’s take ARDS as an example, we know that not every ARDS is the same even if PaO2:FiO2 the same:

  • Etiology: Pulmonary vs non-pulmonary ARDS, ARDS vs COVID-19 ARDS
  • Characteristics: different total respiratory/lung/chest wall mechanics
  • Timing: Early (first 48-96 hrs) vs late (> 96 hrs)
  • Recruitability: some lungs are recruitable vs some are not
  • Different lung weights and lung water
  • Response to PEEP/Prone: some are responders vs some are not
  • Different extents of endothelial injury, perfusion, and pulmonary circulation

The studies that we rely on and supply us with the evidence-based guidelines and recommendations include a mixture of different etiologies of ARDS, different timing, some do not address important issues (recruitability, PEEP responders vs non), and some are from a different era, so have flaws and should not be accepted as religious books.

So how can we support and treat all ARDS patients with the same protocols? At least for me that does not make sense.

What I am proposing is “Individualized Ventilation” and this is not a secret or a new concept by any stretch, matter of fact lots of clinicians do that already.

Knowledge:

Over the last couple decades, our knowledge about lung injury, monitoring (respiratory mechanics, recruitability, alveolar ventilation, dead space, transpulmonary pressures, Electrical impedance tomography are just few examples), asynchronies, ventilator induced lung injury (e.g. mechanical power, driving pressures) have vastly increased, yet we are still practicing like we did in the beginning of the century. We need better education to clinicians, better practical studies and evidence-based guidelines.

Time:

For the last decade we had a serious shortage of clinicians (physicians, respiratory therapists, and nurses) which was exacerbated and highlighted with the COVID-19 pandemic. The shortage of manpower, increase load prevent us from spending enough time at each patient bedside and assessing their interaction with the ventilator, assessing their respiratory mechanics, their response to settings adjustments e.g. PEEP changes. Rather, we depend on x-rays and blood gas results to make our decisions.

Resistance to adapt and change:

This is a big obstacle not only in medicine but in our daily lives in general. Technology has advanced significantly last 2 decades, most of us adopted “smart phones” but not “smart modes” that might help us care for our patients better and more efficient as they can continuously monitor patient-ventilator interactions, respiratory mechanics and adjust themselves as an expert clinician watching the patient continuously 24 hours/day. Monitoring techniques that are not new and shown benefits in clinical practice (esophageal balloons, EIT as examples) are mostly confined to research and very hard to find their way to the bedside. Worse than that, the prone position that have repeatedly been shown large benefits still not widely or adequately utilized.

So what is the recipe and what are the roadblocks that precluding us from doing that?

Granted the technology is not 100% optimal yet but is evolving quickly with the evolving science of Artificial Intelligence. Of course new technology is usually more expensive and not readily available which adds to the big problem.

We need to open our minds to new knowledge and technological advances. We need not restrict clinicians to the use of constricting protocols/modes in their institutions that tie their creative abilities to care for their patients.

I’ll end this on a more optimistic note, we will continue to evolve, improve even if in a slower pace than we like but we will eventually.

What are we doing wrong and how to fix it “Call to arms”

“The first step to solving a problem is realizing that there is one”

Mechanical ventilation has been hampered by so many factors; these were revealed to the world during the COVID-19 pandemic. These problems are validated by the lack of mortality change over the last two decades. Tremendous patient management confusion was exacerbated by a global shortage of clinicians and machines during the pandemic.

To discuss these questions and propose ideas and suggestions to address these issues, a group of mechanical ventilation enthusiasts, educators, developers, and researchers from different regions of the globe, with different expertise, have started to meet.  Initial recommendations hopefully will be published in a hope that could be widely studied and appropriately adopted to change our status quo.   The group is not by any means ignoring or obscuring the tremendous advances made over the years, but the goal is to improve our practice and ourselves. (Watch the first meeting on Ventilation Matters below)

So what are the problems, or the difficulties encountered in the field of mechanical ventilation? It is a big world with so many different cultures, economic states, different education, and practice environments so the difficulties though might be shared by different regions might not be universal.

For the sake of sampling, we will briefly highlight some discussed points, which are not inclusive to all. We believe recognition and owning the problems are a good start.

In the last 40 years, the technological complexity of mechanical ventilators has grown exponentially. Unfortunately, the educational resources developed to teach mechanical ventilation have not kept pace. As a result, there is a growing knowledge gap on the part of clinicians charged with managing mechanical ventilation. This gap greatly affects patient safety, health care cost, and clinician confidence. (Professor Robert L Chatburn).

Education is a key cornerstone to improve our quality of care for our patients. Mechanical Ventilation training on what is new and important is dismal in medical, respiratory, nursing schools.  This curriculum is similarly dwarfed  in specialty training for critical care practitioners. Re-thinking our current educational strategy and investment in education are paramount to supply the tools needed. To that point we might be proposing a separate multidisciplinary fellowship training specific for mechanical ventilation.

The lacks (of interest, enthusiasm, curiosity, etc.) are difficult to identify and tackle but possibly with better support, recognition and empowerment for those clinicians’ complex machine therapy to complex diseases might mitigate the prevalence of the “Lacks” and change the culture.

The technological advances and introduction of Artificial Intelligence in mechanical ventilation are clearly and undeniably witnessed, but our adoption and understanding of such technology is lagging far behind. The resistance to change is palpable and bewildering in daily practice though similar technological advances in other fields like communication, entertainment have been widely accepted.

The research field of mechanical ventilation has flourished over the last 2-3 decades but unfortunately not providing enough answers or sometimes provide conflicting answers. Maybe we need to clarify and concentrate on what are really important research questions and measures we want to tackle.

To add to that issue, there are very few agreed upon guidelines on the utilization of mechanical ventilation modes, settings in different disease. Albeit the ARDS management guidelines been widely adopted and became the gold standard, those guidelines have not changed most of the measured outcomes. The guidelines though important,  oversimplify a very complex disease management (low tidal volume, limiting plateau pressure and empirically setting PEEP to an FiO2 levels).

More and more questions and topics need to be further explored with rational, attainable solutions, and we are hoping for multidisciplinary, multinational collaboration from all who have stakes or skin in the game of mechanical ventilation. Only by working together to self-critique and grade our performance and issue solutions we can move forward for a better future.

Ventilator Induced Lung Injury, the unseen elephant in the room

Those are traumas that happen after placing the patient on the ventilator and the only way to avoid them is to avoid mechanical ventilation which of course can’t always be done.

Those can cause worsening hypoxemia that can prolong mechanical ventilation, lead to multi-system organ dysfunction, and increase mortality.

So the best strategy is to try to avoid them, rapidly diagnose them, and correct what we can.

Our understanding of VILI have spiked over the last two decade. Since the positive results of the low vs high tidal volume trial in ARDS in the beginning of the century, most clinicians start to pay attention to low tidal volume and limiting plateau pressure but is that enough? Is that the answer?

So how are we doing with such understanding, any better? Unfortunately not too good, we can do better, need more work to be done, we owe it to our patients so let’s dig in this very complex problem.

What is VILI:

There are so many types and names we should all be familiar with (Volutrauma, Barotrauma, Biotrauma, Atelectrauma, Shear injury, Diaphragm myotrauma, Oxygen toxicity, SILI, Capillary endothelial injury, etc).

During mechanical ventilation, the lung is under continuous forces during inspiration and expiration, mainly: Stress, Strain, and the frequency of such forces. To be fair, those forces are not solely from the ventilator, but the patient himself play a big role.

Because of the marked heterogeneity of our lung units both in health and disease, different areas of the ventilated lungs are under different stresses (forces per unit area, represented by Trans-pulmonary pressure, i.e. the inside alveolar pressure minus the opposing outside pressure represented by pleural pressure), strain (the dynamic change in shape and deformation of the alveoli).

There has been a debate over the years of what is injurious to the lung, pressures, or volume. The answer is probably both and more. The Mechanical power equation sums the forces in one:

Mechanical Power = VE x (Peak Pressure + PEEP + F/6) / 20

However this equation lacks some important components: the patient-ventilator interaction, trans-pulmonary pressures, dead space, the ventilation distribution to different lung regions.

To summarize the forces we need to pay attention to minute ventilation, respiratory rate, Delta inspiratory pressures, PEEP, tidal volume, trans-pulmonary pressure, patient-ventilator asynchronies, FRC, dead space, and ventilation distribution.

Risks for VILI:

So who develops VILI? We know there are many risks for developing VILI and SILI (self-induced lung injury), but the true incidence and prevalence of VILI is unknown, majorly because of uncertainty in diagnosis.

The terms VALI (ventilator associated lung injury) or VAE (ventilator associated events) were developed based on worsening oxygenation and the need to increase FiO2 and PEEP because of the uncertainty in diagnosis and are very nonspecific and don’t solve the problem.

So why some patients develop VILI, and some don’t? Is it genetic phenotype? The answer is unknown similar analogy are why not all smokers develop COPD or lung cancer.

Diagnosis of VILI:

Unfortunately in clinical practice, it is very difficult to diagnose, with the exception of Barotrauma in the form of pneumothorax, pneumomediastinum which are easily diagnosed radiologically.

Clinical diagnosis remains the only available method and to rule out different other etiologies. Worsening oxygenation, new radiographic evidence of lung infiltrates and respiratory mechanics are usually attributed to infectious Ventilator Associated Pneumonia (VAP) or cardiogenic pulmonary edema leading to the wrong diagnosis, unnecessary antimicrobials and diuretics and most importantly not recognizing the true problem.

No labs or serological markers are currently available for everyday practice for early diagnosis of VILI. There are ample research using different biomarkers in animals, but they remain under investigation and limited to research labs.

Monitoring respiratory mechanics and waveforms can tell us early that there is a new problem but can’t diagnose if the new problem is VILI or just worsening of the initial etiology that landed the patient on the ventilator or other problems (TRALI, VAP, DAH, Pulmonary edema, etc)

What can we do at the bedside?

Obviously, we first need to prevent VILI.  “Prevention is better than cure”

In addition to monitoring and minimizing all the factors included in the equation of mechanical power, there are additional steps that can be taken into consideration.

Monitoring the trans-pulmonary pressure is very important to avoid the excess stress on the alveolar unit both at inspiration and expiration.

Optimizing the PEEP is also crucial according to physiological parameters not based on oxygenation or a table with the one hat fits all concept. Taking in consideration that not one level of PEEP regardless high or low is optimal to all alveolar units in both lungs that have their own opening and closing pressures and under different trans-pulmonary pressures stress.

Optimize and prevent patient-ventilator desynchronies as much as possible, acknowledging the thin line between spontaneous breathing benefits and the possible benefits of muscle paralytics and diaphragmatic dysfunction.

Baby lung or open lung approach: another controversial topic but points to consider are the baby lung is a functional unit and is not anatomical and is not equivalent to 6 ml/kg IBW (which is the normal tidal volume of a healthy person and could be still excessive in lung injury). The open lung approach concentrates on increasing the FRC of the lung through recruitment, different ventilator modes but also carry the risk of excessive volumes and pressures.

Prone position is one of the simple maneuvers that improves the lung inhomogeneity, that improves oxygenations, outcomes and probably reduces VILI but is still underutilized in ARDS, however its use during the COVID-19 pandemic has markedly increased for intubated and non-intubated patients.

Technologies that monitor lung volumes, e.g. CT scans are available but carries the risk of radiation exposure and transporting unstable patients to radiology suits (though mobile units are available). Electrical Impedance Tomography (EIT) is a technology that can be used continuously at the bedside to monitor lung volumes and assess over and under distension in real time helping the clinicians adjust the volumes, pressures, and position of the patient.

Secondly, we need to improve our diagnosis and adjust our strategies of ventilation if VILI is occurring, otherwise we become “The blind leading the blind”

The deficit in diagnosis is a major obstacle. Education is absolute necessity, research on biomarkers of VIL is crucial (similar to troponins as a marker of myocardial injury, and lactic acid as a hypoperfusion marker in shock states). We need reliably sensitive and specific markers (serologic or based on breath analysis), fast, not too expensive so can be incorporated at the bedside.

The future:

With the advance in technology, education, research, artificial intelligence, I am extremely hopeful that we will do better eventually specifically in the topic of VILI and mechanical ventilation in general.

I can see alert systems all incorporated in one place probably within the ventilator that incorporates different measures and maybe analyze the expiratory gas from the patient recognizing early VILI and automatically correct the issues or gives suggestions to the bedside clinicians.

To summarize:

Personalized ventilation to each patient

Spend the time at bedside

More education and improve enthusiasm

More research

Uniting forces from all who have stake in mechanical ventilation (clinicians, societies, universities, manufacturers)

New technologies and artificial intelligence

The Revolution Begins (The 6 ml/kg)

In 2000, I was an internal medicine resident highly fascinated with yet poorly educated about the field of critical care medicine specifically the science of mechanical ventilation. When the ARMA trial of low tidal volume 6 vs 12 ml/kg IBW came out that year, I thought why 12? Did we even use 12 ml/kg even then?

The joke between us at the time was, any patient goes on the ventilator, the settings are AC (I never use that horrible term unless I am talking about air conditioning), tidal volume 500, respiratory rate of 15 and PEEP 5 regardless. So, for an average patient with IBW 70 kg, that is equivalent to 7.1 ml/kg, little higher for lower IBW and little lower for higher IBW. I cannot believe we used 840 ml for an average person to start with.

For the last 21 years, I have been arguing that it is not the tidal volume only that injures or add injury to the injured lung, it is the pressures applied to the alveoli that causes the stress and strain on those alveoli. Not only the plateau pressure or the driving pressure alone but the sum of forces (trans-pulmonary pressure) from inside (plateau pressure) and outside (pleural pressure) as estimated by an esophageal balloon.

I just refuse the one size hat fits all concept, just does not make any physiological sense.

The 6 ml/kg could be injurious to a lung that has > 50% of alveoli collapsed, and 10 ml/kg could be ok for a lung that has most of its alveoli open via the “open lung approach”.

Heretic and ignorant was called to unbelieve or disregard the ARDS network and their guidelines that were adopted by every society and hospital. Though in every case of mechanical ventilation, I try to use the lowest tidal volume, lowest driving pressure and lowest plateau pressure I can achieve. In difficult cases, I indeed use the esophageal balloon manometry to calculate the total respiratory compliance and its two components: lung and chest wall, and guide my pressures applied (driving pressures and PEEP) through monitoring the end inspiratory and end expiratory trans-pulmonary pressures even in the non- conventional modes like APRV and during prone position.

I am also still waiting for the Electrical Impedance Tomography (EIT) to be commercially more available as it will give us a whole new insight in this issue and of how we apply mechanical ventilation.

But I was not alone, highly respected great minds in mechanical ventilation (Tobin, Amato, Gattinoni, just to name a few) have argued that it is the pressure whether plateau pressure, driving pressure that is injurious. The eternal fights between the most famous and intelligent minds in mechanical ventilation filled the literature of whether it is the volume or the pressure, with evidence to support their claims. I would add that it is probably both.

We also do not talk much about the asynchronies that happen a lot especially in the low tidal volume strategy that are injurious by themselves.

A recent meta-analysis of five randomized trials was published this month of July 2021 have shown that indeed it is the driving pressure more than the tidal volume that worsens mortality through ventilator induced lung injury. An editorial for that study by Dr. Tobin (one of the people you should listen to about mechanical ventilation) titled “The Dethroning of 6 ml per kg as the “go-to” Setting in ARDS” made me jump to write this in support of his and others who are fighting the good fight of ventilator induced lung injury.

I think the time has come to treat every patient on a physiologic basis and parameters not like cars were the gas tank gets filled with a fixed certain amount of gas.

To summarize, I want to be clear, I am not advocating for high tidal volumes but advocating for the lowest safest tidal volume, driving pressures, plateau pressures, transpulmonary pressures possible.

Yet the hard reality is our lungs and respiratory system in general are very heterogenous, and ventilator lung injury to some extent cannot be totally prevented as different areas of the lungs are not subjected to the same tidal volumes, driving pressures, plateau and transpulmonary pressures. Those are the sum of both lungs. Unless we can ventilate each lobe, each segment, each subsegment separately.

Not to leave at a pessimistic view, I am very hopeful that our understanding, monitoring and treatment techniques will continue to grow and improve.

ICU Nurses and the Ventilators

ICU nurses are the highly trained stables of an ICU. They spend most of their time providing direct patient care and offer first line defense to patients who are usually tangled in a mesh of multiple pumps, life saving devices and monitors.

One of the most important machine in the room is possibly the mechanical ventilator.

So, what is the role of a nurse when it comes to the ventilator?

Traditionally in the United States, the ventilator is considered a property of the respiratory therapists.  Any issue or alarm of the ventilator triggers a call to the respiratory therapist to troubleshoot a problem.  However, some of those alarms or issues might be so emergent that there is not enough time to call a respiratory therapist especially when not directly available in the ICU or if he or she is stuck in another procedure.

The ventilator is a complex machine with different modes, settings, and alarms that respiratory therapists have gone through rigid training in a two or four-years college to master the skill.

Nevertheless, nurses have their own critical roles at the ICU, and are not practically trained on the ventilator, and clinical experience might vary.

We believe training ICU nurses on the basic modes of a ventilator can greatly benefit the patients. Teaching them the basic operation of a ventilator (e.g. what the different alarms mean, how to troubleshoot those issues etc.) are not intended to overburden the already busy nurses, but to empower them to take on a more active role in the patients’ welfare.

It might help their patients wean and get liberated off the ventilator faster and safer.

We believe education and knowledge is power.  At SMV, we will offer educational materials designed specifically for this purpose.  With that said, lets improve our knowledge to save lives.

How much Smarter and Intelligent can we get

AI & Copyright: What is Old is New Again? - Copyright Clearance Center

The science of mechanical ventilation has come a long way over the last three to four decades. Our understanding of the pathology of diseases, respiratory mechanics, and the technology has grown substantially.

With the development of microprocessors, numerous new “smart” and “intelligent” modes have been developed with the hope of improving our goals during mechanical ventilation of safety, comfort, and liberation.

No doubt, this is not the end of the road, matter of fact it might be just the beginning.  So it is time to stop and ask ourselves multiple question.

Are  those new modes really better than the older modes ?

What do we need from any new mode ?

What else we need from the new generation ventilators ?

How much intelligent we want the ventilator to be ?

Are  those new modes really better than the older modes ?

You might agree or disagree with me, but our mortality from severe respiratory failure remains unacceptably high enough and has not decreased significantly over the last 2 decades. Our failure to wean or liberate our patients from mechanical ventilators has not changed much either. Thus my opinion is no, we are not doing much better with the currently exciting modes. To be fair, we can not blame the new modes as our current mortality data are not calculated using the new modes, and the studies comparing those modes to the “old conventional modes” are few and small.

What do we need from any new mode ?

No doubt we need a safe mode that minimizes lung damage through reducing “ventilator induced lung injury”. The problem with that is we still can not agree on what injures the lung, is it the applied pressures (Driving pressure/PEEP), the trans-pulmonary pressure, the tidal-volume, most likely a combination of all. In reality and in my pessimistic opinion, is we will never be able to eliminate ventilator induced lung injury. Why not? The fact is our lungs which is the largest organ in our body is very heterogeneous both in health and more importantly in disease. We might be protecting a part of it while simultaneously hurting another part, unless we can ventilate each subsegment of the lung,  or each alveoli independent of its neighbor one.

That is why, the one hat fits all strategy in each disease will not work. All what we can do with what we have now is an individual to individual approach to mechanical ventilation, based on specific monitoring, and interaction with the patient.

We need a mode that can liberate the patient faster, and keep him off the ventilator longer. Currently multiple modes started to exactly do that. The studies and data remains small and not very convincing.

We need a mode that can change it’s input breath by breath based on the patients’ actual respiratory mechanics and how they are interacting with the ventilator to reduce patient-ventilator asynchronies. Currently we have those intelligent modes that can monitor the respiratory mechanics and adjust its inputs but they do so according to the clinician set parameters. Those parameters are usually pressures, volume, respiratory rate, etc. Not good enough, we need the changes to be according to physiologic respiratory mechanics.

What else we need from the new generation ventilators ?

As above, a mode that really interacts with the patient. I believe we need more monitoring, more of a multi-modality monitoring that would be integrated in the decision making process and the feedback loop of the mode.

The ventilator graphics (volume, pressure, flow), the loops (pressure-volume, flow-volume), oxygen saturation, end-tidal carbon dioxide are all great information the ventilator monitors for us. Are those enough ? Absolutely not.

Accurate respiratory mechanics monitoring are crucial. Measuring patients’ muscle efforts or lack of are very important and usually ignored. Older and fairly newer technologies like esophageal balloon manometry, Electrical Impedance Tomography adds much more information that we really need. I believe every new ventilator should have those monitoring technologies. The question is, are we clinicians will be able to absorb all those information and apply them to the benefits of our patients ?

How much intelligent we want the ventilator to be ?

My opinion in answering that question, is yes we need the ventilator to be much more intelligent. Some fear that the ventilators will turn into the “Terminator”. They will be so independent and does not need a human clinician and we will all loose our jobs. I do not believe that scenario. Physicians and respiratory therapists are already overwhelmed and considered hot commodities, especially in the COVID-19 era.

We need an intelligent friend who is monitoring and managing the patient in an intelligent, knowledgeable, safe way breath to breath.

Artificial intelligence (AI) is the answer. It can process much more information than humans, act faster.

In conclusion, the future of mechanical ventilation is very interesting and exciting. We are just starting to scratch the surface, and lots more great things to come. Soon we will be looking back and saying wow did we really used to do that in the early 21st century. So stay tuned.

Ehab Daoud
